VDAC1 Rabbit Polyclonal Antibody

RMB: 618 特別割引 1500

製品仕様

今すぐ注文，【现货】

問い合わせをクリック

お問い合わせ

メール: sales@huabio.cn

電話: 0571-88062880

代理店を調べる

Catalog# R1307-1

VDAC1 Rabbit Polyclonal Antibody

Application

  • WB

  • IF-Cell

  • IHC-P

Reactivity

  • Human

  • Mouse

  • Rat

Predicted reactivity

  • Zebrafish

予測される種属に対するアフターサービスのサポート
This product has been cited in peer reviewed publications, see list HERE

概要

製品名

VDAC1 Rabbit Polyclonal Antibody

抗体の種類

Rabbit Polyclonal Antibody

免疫原

Synthetic peptide within human VDAC1 aa 188-231.

種属反応性

Human, Mouse, Rat (Predicted: Zebrafish)

予測される種属に対するアフターサービスのサポート

検証された応用例

WB, IF-Cell, IHC-P

分子量

Predicted band size: 31 kDa

陽性対照

HeLa cell lysate, Jurkat cell lysate, A431 cell lysate, Raji cell lysate, HepG2 cell lysate, SW480 cell lysate, A549 cell lysate, NIH/3T3 cell lysate, C2C12 cell lysate, C6 cell lysate, Mouse skeletal muscle tissue lysate, Rat skeletal muscle tissue lysate, Hela, human skeletal mucle tissue, mouse skeletal mucle tissue, rat skeletal mucle tissue.

結合

unconjugated

RRID

AB_3073220

製品の特徴

形態

Liquid

濃度

1ug/ul

保存方法

Store at +4℃ after thawing. Aliquot store at -20℃ or -80℃. Avoid repeated freeze / thaw cycles.

保存用バッファー

1*PBS (pH7.4), 0.2% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

アイソタイプ

IgG

精製方法

Immunogen affinity purified.

応用希釈度

  • WB

  • 1:1,000-1:2,000

  • IF-Cell

  • 1:200

  • IHC-P

  • 1:500

論文における応用例

WB 確認する 1 以下の論文

ターゲット

機能

Voltage-dependent anion-selective channel (VDAC1) (also referred to as porin, isoform 1) is a small protein, originally discovered in the outer membrane of mitochondria where it constitutes the major pore-forming protein. The porin protein VDAC1 allows to the outer-most membrane of the mitochondrion free permeability to low molecular-weight solutes. VDAC1 has been shown to co-immunoprecipitate with the anti-apoptotic protein Bcl-2 and suggested to be involved in forming the mitochondrial pore which releases cytochrome c during apoptosis.

背景文献

1. "Influenza virus PB1-F2 protein induces cell death through mitochondrial ANT3 and VDAC1."Zamarin D., Garcia-Sastre A., Xiao X., Wang R., Palese P. PLoS Pathog. 1:40-54(2005)

2. "Solution structure of the integral human membrane protein VDAC-1 in detergent micelles." Hiller S., Garces R.G., Malia T.J., Orekhov V.Y., Colombini M., Wagner G. Science 321:1206-1210(2008)

配列相同性

Belongs to the eukaryotic mitochondrial porin family.

組織特異性

Heart, liver and skeletal muscle.

翻訳後修飾

Phosphorylation at Ser-193 by NEK1 promotes the open conformational state preventing excessive mitochondrial membrane permeability and subsequent apoptotic cell death after injury. Phosphorylation by the AKT-GSK3B axis stabilizes the protein probably by preventing ubiquitin-mediated proteasomal degradation.; Ubiquitinated by PRKN during mitophagy, leading to its degradation and enhancement of mitophagy. Deubiquitinated by USP30.

亜細胞局在

Mitochondrial membrane, cell membrane

UNIPROT #

SwissProt: P21796 Human

別名

N2441 antibody

OMP2 antibody

POR1 antibody

hVDAC1 antibody

MGC111064 antibody

Mitochondrial Porin antibody

Outer mitochondrial membrane protein porin 1 antibody

Plasmalemmal porin antibody

Porin 31HL antibody

Porin 31HM antibody

展開

画像

  • Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/1,000 dilution.<br /><br />Lane 1: HeLa cell lysate<br />Lane 2: Jurkat cell lysate<br />Lane 3: A431 cell lysate<br />Lane 4: Raji cell lysate<br />Lane 5: HepG2 cell lysate<br />Lane 6: SW480 cell lysate<br />Lane 7: A549 cell lysate<br /><br />Lysates/proteins at 20 µg/Lane.<br /><br />Predicted band size: 31 kDa<br />Observed band size: 31 kDa<br /><br />Exposure time: 1 minute 30 seconds;<br /><br />4-20% SDS-PAGE gel.<br /><br />Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/1,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody (<a href="/products/HA1001" style="font-weight: bold;text-decoration: underline;">HA1001</a>) at 1:100,000 dilution was used for 1 hour at room temperature.

    Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (R1307-1) at 1/1,000 dilution.

    Lane 1: HeLa cell lysate
    Lane 2: Jurkat cell lysate
    Lane 3: A431 cell lysate
    Lane 4: Raji cell lysate
    Lane 5: HepG2 cell lysate
    Lane 6: SW480 cell lysate
    Lane 7: A549 cell lysate

    Lysates/proteins at 20 µg/Lane.

    Predicted band size: 31 kDa
    Observed band size: 31 kDa

    Exposure time: 1 minute 30 seconds;

    4-20% SDS-PAGE gel.

    Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (R1307-1) at 1/1,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1:100,000 dilution was used for 1 hour at room temperature.

  • Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/2,000 dilution.<br /><br />Lane 1: NIH/3T3 cell lysate (20 µg/Lane)<br />Lane 2: C2C12 cell lysate (20 µg/Lane)<br />Lane 3: C6 cell lysate (20 µg/Lane)<br />Lane 4: Mouse skeletal muscle tissue lysate (40 µg/Lane)<br />Lane 5: Rat skeletal muscle tissue lysate (40 µg/Lane)<br /><br />Predicted band size: 31 kDa<br />Observed band size: 31 kDa<br /><br />Exposure time: 6 seconds; ECL: K1801;<br />4-20% SDS-PAGE gel.<br /><br />Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/2,000 dilution was used in primary antibody dilution (K1803) at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (<a href="/products/HA1001" style="font-weight: bold;text-decoration: underline;">HA1001</a>) at 1/50,000 dilution was used for 1 hour at room temperature.

    Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (R1307-1) at 1/2,000 dilution.

    Lane 1: NIH/3T3 cell lysate (20 µg/Lane)
    Lane 2: C2C12 cell lysate (20 µg/Lane)
    Lane 3: C6 cell lysate (20 µg/Lane)
    Lane 4: Mouse skeletal muscle tissue lysate (40 µg/Lane)
    Lane 5: Rat skeletal muscle tissue lysate (40 µg/Lane)

    Predicted band size: 31 kDa
    Observed band size: 31 kDa

    Exposure time: 6 seconds; ECL: K1801;
    4-20% SDS-PAGE gel.

    Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (R1307-1) at 1/2,000 dilution was used in primary antibody dilution (K1803) at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.

  • <span style="font-weight: bold;">☑ Knockdown (KD)</span><br /><br />Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/1,000 dilution.<br /><br />Lane 1: HEK293-si NT cell lysate (10 µg/Lane)<br />Lane 2: HEK293-si VDAC1#1(no heat) cell lysate (10 µg/Lane)<br />Lane 3: HEK293-si VDAC1#2(no heat) cell lysate (10 µg/Lane)<br /><br />Notice: no heat means the lysate is not boiled.<br /><br />Predicted band size: 31 kDa<br />Observed band size: 31 kDa<br /><br />Exposure time: 2 minutes; ECL: K1801;<br />4-20% SDS-PAGE gel.<br /><br /><a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a> was shown to specifically react with VDAC1 in HEK293-si NT cells. No band were observed when HEK293-si VDAC1 samples were tested. HEK293-si NT and HEK293-si VDAC1 samples were subjected to SDS-PAGE. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM in TBST for 1 hour at room temperature. The primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>, 1/1,000) and Loading control antibody (Rabbit anti-GAPDH, <a href="/products/ET1601-4" style="font-weight: bold;text-decoration: underline;">ET1601-4</a>, 1/10,000) were used in 5% BSA at 4℃ overnight. Goat Anti-rabbit IgG-HRP Secondary Antibody (<a href="/products/HA1001" style="font-weight: bold;text-decoration: underline;">HA1001</a>) at 1:100,000 dilution was used for 1 hour at room temperature.

    ☑ Knockdown (KD)

    Western blot analysis of VDAC1 on different lysates with Rabbit anti-VDAC1 antibody (R1307-1) at 1/1,000 dilution.

    Lane 1: HEK293-si NT cell lysate (10 µg/Lane)
    Lane 2: HEK293-si VDAC1#1(no heat) cell lysate (10 µg/Lane)
    Lane 3: HEK293-si VDAC1#2(no heat) cell lysate (10 µg/Lane)

    Notice: no heat means the lysate is not boiled.

    Predicted band size: 31 kDa
    Observed band size: 31 kDa

    Exposure time: 2 minutes; ECL: K1801;
    4-20% SDS-PAGE gel.

    R1307-1 was shown to specifically react with VDAC1 in HEK293-si NT cells. No band were observed when HEK293-si VDAC1 samples were tested. HEK293-si NT and HEK293-si VDAC1 samples were subjected to SDS-PAGE. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM in TBST for 1 hour at room temperature. The primary antibody (R1307-1, 1/1,000) and Loading control antibody (Rabbit anti-GAPDH, ET1601-4, 1/10,000) were used in 5% BSA at 4℃ overnight. Goat Anti-rabbit IgG-HRP Secondary Antibody (HA1001) at 1:100,000 dilution was used for 1 hour at room temperature.

  • ICC staining VDAC1 in Hela cells (green). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS and counterstained with DAPI in order to highlight the nucleus (blue).

    ICC staining VDAC1 in Hela cells (green). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS and counterstained with DAPI in order to highlight the nucleus (blue).

  • Immunohistochemical analysis of paraffin-embedded human skeletal mucle tissue with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded human skeletal mucle tissue with Rabbit anti-VDAC1 antibody (R1307-1) at 1/500 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (R1307-1) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded mouse skeletal mucle tissue with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded mouse skeletal mucle tissue with Rabbit anti-VDAC1 antibody (R1307-1) at 1/500 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (R1307-1) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded rat skeletal mucle tissue with Rabbit anti-VDAC1 antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/R1307-1" style="font-weight: bold;text-decoration: underline;">R1307-1</a>) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded rat skeletal mucle tissue with Rabbit anti-VDAC1 antibody (R1307-1) at 1/500 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (R1307-1) at 1/500 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

ご注意ください: All products are "FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE"

論文での実績

Filter:
  1. WB
